CARGO TANK MONITORING SYSTEM
CARGO-2000 (MAGNETIC FLOAT TYPE)
- GENERAL INFORMATION
- MAGNETIC FLOAT TYPE CARGO TANK MONITORING SYSTEM is basically designed to measure the level inside cargo tanks and occur alarms when the measured value exceeds the limit.
- This system uses float type level sensors.
- Marsen's magnetic float level sensor has been developed based on the long time of the marine field experience and its performance and stability are proved alread.
- This system is designed according to SOLAS & MARPOL 73/78 & IMO Rules.
FEATURE & ADVANTAGE
- Proper price
- Easy maintenance
- Simple structure
- Non contact measurement
- Touch screen / Easy operation
- Measurable on liquid cargo
APPLICATION
All kinds of oil & chemical tankers
PERATION PRINCIPLE & SYSTEM COMPOSITION
CARGO-2000 is composed of float sensors for measuring the level, control panel for monitoring the measured value by touch LCD and barrier for ex-proof.
Sets of reed switches are positioned along the length of the guide pipe.
As the float travels up and down the guide pipe in accordance with the level of the liquid in the tank, the flux emitted from magnets within
the float works upon the reed switches ON or OFF.
By measuring voltage across the transmitter circuit, the level of the liquid can be calculated according to the changes in circuit resistance. reed switches ON or OFF.
The converted signal is sent to the control box via I.S. barrier in the control room or to a local indicator as the case may be.
TECHNICAL SPECIFICATION
- SENSOR TYPE
- MEASURING RANGE
- ACCURACY
- POWER
- SIGNAL OUTPUT
- EX PROOF
- AMBIENT TEMPERATURE
- MATERIAL
- IP GRADE
- MAG.FLOAT TYPE
- 0~35m
- ±10mm
- AC 110/220V, 50/60Hz
- 4~20mA with HART
- Ex ia IIC T6
- -25~75°C
- SUS316
- IP 68
COMPONENTS / OUTLINE
